Overview
The B2 is a fanless mini PC that offers high performance and low power consumption in a compact and silent design. It features two LAN ports and two HDMI ports, making it ideal for network applications and dual-display setups.ompatible with Windows 10, Linux, and other operating systems, and can be easily mounted on the back of a monitor or TV with the included bracket.
Specifications
| BIOS | AMI BIOS, ACPI Supported |
| Support calls on function automatically | |
| Support Wake-On-LAN | |
| Chipset | Intel Broadwell-U |
| Memory | 2* SO-DIMM DDR3L Slot |
| Support 4GB/8GB/16GB | |
| Dual Channel, DDR3L 1333/1600 LPDDR 1333/1600 | |
| Storage | SSD: 8GB/16GB/32GB/64GB/128GB/256GB |
| HDD: 80GB/160GB/320GB/500GB/750GB/1TB | |
| Support 2*Mini PCIE Msata SSD+1* 2.5″ HDD/SSD (SSD Max.512G*2, HDD Max. 1TB) | |
| Operating System | Windows (OEM) or Linux |
| Audio | ALC897 chip, 7.1 channel sound |
| Intel Lynx Point-LP HDA | |
| Network | Onboard Redlrik RTL8186E PCI-E Gigabit Ethernet NIC |
| Onboard RTL8111DL 10/100mbps Base T LAN | |
| Video | Intel HD Graphics 6000 |
| Support HDMI Full Screen HD Playback | |
| Support 4K HD DP Interface | |
| Support 3D Blu-Ray | |
| I/O Ports | |
| I/O Specifications | 2* RJ45 10/100/1000Mbps Lan port |
| 1* Power indicator and switch | |
| 2*HDMI Port (Double HDMI ports can transfer with VGA or DVI) | |
| 4*USB2.0+4USB3.0 | |
| 1*DC IN | |
| 1* SD Card Reader | |
| 1*MIC | |
| 1*SPK | |
| 1* Fiber Port | |
| Power and Working Environment | |
| Input | DC100-240V AC/50-60Hz |
| Output | DC 12V~19V/5A |
| Operating Temperature | 0/70 Centigrade(32F~140F) |
| Storage Temperature | (-20/+80)Centigrade |
| Relative Humidity | 10%~90%(non-condensing) |
| Energy-Saving | Support Energy-saving technology, Speedstep |
| 64 bit computing | Support 64 bit computing |
| Virtualization | Intel VT-x |
| Hyper-Threading | Support Hyper-Threading (Hyper-Threading) Technology |
| Product Dimension&Details | |
| Noise | Fanless System |
| Size | 21*17.5*4.5CM |
| Weight | 3KG |
| Consumption | 15W-28W |
| Shell | Black Color with aluminum alloy |
| Package Box | Neutral Color Box or INCTEL Color Box |
| Content | Mini PC device, Power Adapter, Desk base, Antennas |
