Overview
Partaker I3 Industrial PC is a durable and reliable device that can run Windows 10, Linux Ubuntu, and other operating systems. It has a range of Intel CPU options, from Celeron to Core i7, up to 64GB of RAM, and various storage options. It supports HDMI, VGA, COM, WiFi, Bluetooth, and M.2 PCIE WiFi slot. It has a sleek and sturdy aluminum alloy case, with mounting ears for wall-mounted, embedded, or desktop installation. It comes with a power supply, a power cord, wifi antennas, and a warranty card. It is certified by CE, FCC, and ROHS. Partaker I3 Industrial PC is a great choice for industrial, commercial, or personal use.
Specifications
| Material | Aluminum alloy |
| Colour | Black |
| Size | 234 x 150 x 43mm |
| Weight | 2.5Kgs |
| Insallation Method | With mounting ears |
| Wall-mounted, embedded, desktop | |
| CPU | Intel® Celeron® Processor 2955U (2M Cache, 1.40 GHz) |
| Intel® Core™ i3-4005U Processor (3M Cache, 1.70 GHz) | |
| Intel® Core™ i3-5005U Processor (3M Cache, 2.00 GHz) | |
| Intel® Core™ i3-6157U Processor (3M Cache, 2.40 GHz) | |
| Intel® Core™ i3-7167U Processor (3M Cache, 2.80 GHz) | |
| Intel® Core™ i3-8140U Processor (4M Cache, up to 3.90 GHz) | |
| Intel® Core™ i5-4278U Processor (3M Cache, up to 3.10 GHz) | |
| Intel® Core™ i5-5287U Processor (3M Cache, up to 3.30 GHz) | |
| Intel® Core™ i5-8250U Processor (6M Cache, up to 3.40 GHz) | |
| Intel® Core™ i7-8550U Processor (8M Cache, up to 4.00 GHz) | |
| Intel® Core™ i7-10510U Processor (8M Cache, up to 4.90 GHz) | |
| Intel® Core™ i5-10310U Processor (6M Cache, up to 4.40 GHz) | |
| Intel® Core™ i5-1135G7 Processor (8M Cache, up to 4.20 GHz) | |
| Intel® Core™ i7-1165G7 Processor (12M Cache, up to 4.70 GHz) | |
| Intel® Core™ i5-1235U Processor (12M Cache, up to 4.40 GHz) | |
| Intel® Core™ i7-1255U Processor (12M Cache, up to 4.70 GHz) | |
| Chipset | SOC |
| Network Card | 1 x Intel RTL 8168/8111/8112 gigabit lan |
| WiFi and Bluetooth | With dual antennas, 802.11ac 2.4+5Ghz, bt 4.0/4.2 |
| Memory | 2 x SO-DIMM DDR3L 1333/1600, up to 16GB RAM |
| 2 x SO-DIMM DDR4, up to 64GB RAM(I3 8140U/I5 8250U/I7 8550U/I5 10310U/I7 10510U/I5 1135G7/I7 1165G7/I5 1235U/I7 1255U) | |
| Storage | 1 x 2.5 inch hard disk bay/1 x mSATA |
| 1 x 2.5 inch hard disk bay/1 x mSATA/1 x M.2 2280 (SATA/NVME) | |
| Expand | 1 x M.2 PCIE WiFi slot |
| Front Panel | 1 x Power button |
| 4 x USB2.0/ 3 x USB2.0 | |
| Rear Panel | 1 x DC_in |
| 1 x HDMI | |
| 1 x VGA | |
| 1 x Lan | |
| 4 x USB3.0 | |
| 1 x Audio | |
| 2 x COM RS232 | |
| 2 x WiFi antennas | |
| Bios | AMI bios |
| System Support | Windows 10, linux ubuntu etc |
| Power Supply | DC100-240V AC/50-60Hz, DC 12V/3A-5A/ 19V/5A |
| Packing List | Partaker I3 industrial pc, power supply, power cord, wifi antennas, warranty card |
| Operating Temperature | 0°C~70°C Centigrade (32°F~140°F) |
| Storage Temperature | -20°C~80°C Centigrade (-68°F~176°F) |
| Relative Humidity | 10%~90% (non-condensing) |
| Certification | CE FCC ROHS |
