Overview
This multi-faceted firewall unit supports a range of 2th/3th Intel processors, delivering diverse installation choices (Rack/Wall/Desktop). With 8 Intel LAN ports and broad OS compatibility, it offers expandable storage, dual display support, and versatile connectivity. Crafted with industrial-grade materials, it complies with rigorous CE, FCC, CCC, and ROHS certifications, ensuring reliability in diverse operational environments
Specifications
| Material | Iron, Aluminum panel |
| Colour | Gray |
| Size | 440 x285 x 45(mm)(without mounting ear) |
| Weight | 7.5Kgs |
| Insallation Method | Rack Mounting/Wall Mounting/Desktop Mounting |
| CPU | Supports 2th/3th Intel®celeron/Core™ i3/i5/i7 processors |
| (1005M/I3-2350M/3110M/I5-2520M/3320M/I7-3520M/3630QM) I5-3317U/I7-3517U | |
| Network Card | 8 Intel 82583V network interfaces (optional 82574L) |
| Graphic | Depend on CPUs |
| Memory | Support 1 x DDR3L 1600 MHz SODIMM memory slot, maximum support 8GB |
| Storage | 1 x mSATA SSD |
| 1 2.5-inch hard drive | |
| Display | 1 x VGA, 1 x HDMI (Optional) |
| Expand | 1 x Mini-PCIE slot (WIFI/Bluetooth with optional USB protocol), 1× Mini-PCIE slot (4G module) |
| Support 1 PCI-E X8 PCI-E expansion slot | |
| Front Panel | 1 x VGA |
| 2 x Cooling fan | |
| 1 x Switch | |
| 1 x AC socket | |
| Rear Panel | 1 x Console |
| 2 x 3.0 | |
| 8 x LAN | |
| System Support | Windows,10,Server2012/EXSI/Ikuai/Mikrotik/Openwrt/Ubuntu/Centos/Pfsense/Linux |
| BIOS | AMI EFI BIOS |
| Cooling Mode | With Fan |
| Power Supply | Industrial grade power supply Taiwan MEAN WELL LRS-50-12 Input: 100-240V~1.0A Output: 12V4.2A |
| Packing List | S08 firewall, power cord, warranty card |
| Operating temperature | -0~+50°C (commercial HDD), -20°C~+50°C (industrial SSD), surface air flow |
| ambient temperature | 5~90°C relative humidity, non-condensing |
| Certification | CE, FCC, CCC, ROHS |
